RS-HFIQ – ein preiswerter SDR-TRX auf Kickstarter.com
The RS-HFIQ is a high performance Software Defined Radio (SDR) 5W Transceiver for CW, SSB, AM, FM and digital modes.
Software: HDSDR, LINRAD, QUISK, GNU Radio (Linux)
Specifications
- Frequency Range – 3-30 MHz (performance guaranteed on 80/60/40/30/20/17/15/12/10M ham bands)
- Sensitivity – MDS <-128 dBm on 80M dropping to <-135 on 10M (depending on processing bandwidth and sound card performance)
- Noise Figure – <15 dB on 80M decreasing to <10 dB on 10M
- TX Power 5W typical, 4W minimum
- LO Feed-thru < -50 dBc @ 5W output
- Spurious and Harmonics <-50 dBc typical <43 guaranteed
- DC Power 13.8VDC, 2A max, plus USB power for the Arduino Nano
Lieferdatum April 2017, die Kickstarter Kampagne läuft bis Ende November 2016.
Es gibt dabei folgende Optionen:
- nur die Platine 30 US$
- das komplette Board, bestückt und getestet: 239 US$
- das bestückte Board mit einem Gehäuse: 269 US$
- Board, Gehäuse und Bausatz für eine 50W Endstufe: 519 US$
- Board, Gehäuse, Bausatz für die 50W Endstufe und einen automatischen Antennentuner: 689 US$
- Bei einer Sammelbestellung für 5 Stück (Boards mit Gehäuse) 1.249 US$ ca. 250 $ pro Einhei.
