A new version (0.94-1313) of the Red Pitaya SDR application

Eine neu Version von Pavel ist hier im Blog und im Forum verfügbar!

SDR (Software Defined Radio) Transceiver

by pavel
Thu Sep 08, 2016 9:49 pm

A new version (0.94-1313) of the Red Pitaya SDR application compatible with HPSDR is ready. I uploaded it to the Red Pitaya application marketplace and updated the customized SD card image available from the following link:

http://pavel-demin.github.io/red-pitaya … iver-hpsdr

This new version includes the following improvements:

  • reduced CW signal latency from ~15 ms to ~2 ms
  • increased RX signal levels by 10 dB
  • added TX drive level control via DS1803-10 (thanks to ON3VNA)

Some information about the CW functionality can be found at this link.

Angepasste Versionen von CQNRW_PowerSDR Stand 3.3.9 für die neue HPSDR-Version_1303 von Pavel

Hier noch vor unserem Urlaub eine korrigierte PowerSDR.exe passend zur neuen Version von Pavel HPSDR_1303.

Installation:
Einfach in eine bereits vorhandene aktuelle Version ‘_MOD’ entpacken
und eine Verknüpfung auf den Desktop zur PowerSDR_1303.exe legen.
Wenn man wieder die Vorgänger-Version haben will, dann muß man
im Setup das Häkchen ‘DriveLevel by Audio’ reaktivieren.

73 Detlev de DL4AOI / Jörg de DD8JM

CQNRW_PowerSDR_1303

New version of the Red Pitaya SDR application compatible with HPSDR von Pavel 0.94-1303

Hello Jörg and Detlev,

This is to let you know that a new version (0.94-1303) of the Red Pitaya SDR application compatible with HPSDR is ready. I uploaded it to the Red Pitaya application marketplace and updated the customized SD card image available from the following link:

http://pavel-demin.github.io/red-pitaya-notes/sdr-transceiver-hpsdr

This new version includes the following improvements:

– reduced TX signal latency from ~350 ms to ~50 ms

– connected outputs for 10 dB and 20 dB attenuators control to the pins DIO2_P – DIO3_P of the extension connector E1

– connected outputs for Hermes Ctrl pins to the pins DIO4_P – DIO7_P of the extension connector E1

– enabled internal pullup on the input pins (Dot, Dash, PTT)

– added TX drive level control that scales samples sent to DAC (lower levels decrease the DAC resolution, SNR, etc)

– added a very basic CW functionality that works with a straight key or an external keyer connected to the pin DIO2_N of the extension connector E1 (CW signal is generated when one of the CW modes is selected in PowerSDR mRX PS and the pin DIO2_N is connected to GND)

In the attachment is a drawing of the extension connector E1 showing pins used by this new version.

Best regards,

Pavel

RF and GPIO connections

  • input for RX1 is connected to IN1
  • inputs for RX2 and RX3 are connected to IN2
  • output for TX is connected to OUT1
  • output for a RX/TX switch control (PTT-out) is connected to pin DIO0_P of the extension connector E1
  • output for a pre-amplifier/attenuator control is connected to pin DIO1_P of the extension connector E1 (this pin is controlled by the first ATT combo-box in PowerSDR mRX PS)
  • outputs for 10 dB and 20 dB attenuators control are connected to the pins DIO2_P – DIO3_P of the extension connector E1
  • outputs for Hermes Ctrl pins are connected to the pins DIO4_P – DIO7_P of the extension connector E1
  • inputs for PTT, DASH and DOT are connected to the pins DIO0_N, DIO1_N and DIO2_N of the extension connector E1

GPIO connections

ALEX connections

The ALEX module can be connected to the pins DIO4_N (Serial Data), DIO5_N (Clock), DIO6_N (RX Strobe) and DIO7_N (TX Strobe) of the extension connector E1. The board and the protocol are described in the ALEX manual.

The HPSDR signals sent to the TPIC6B595 chips are shown on the following diagram:

ALEX connections

I2C connections

This interface is designed by Peter DC2PD. The sdr-transceiver-hpsdr.c server communicates with one or two PCA9555 chips connected to the I2C pins of the extension connector E2.

HPSDR signals sent to the PCA9555 chip at address 0:

PCA9555 pins HPSDR signals
P00 – P06 Open Collector Outputs on Penelope or Hermes
P07 – P10 Attenuator (00 = 0dB, 01 = 10dB, 10 = 20dB, 11 = 30dB)
P11 – P12 Rx Antenna (00 = none, 01 = Rx1, 10 = Rx2, 11 = XV)
P13 – P14 Tx Relay (00 = Tx1, 01= Tx2, 10 = Tx3)

HPSDR signals sent to the PCA9555 chip at address 1:

PCA9555 pins HPSDR signals
P00 select 13MHz HPF (0 = disable, 1 = enable)
P01 select 20MHz HPF (0 = disable, 1 = enable)
P02 select 9.5MHz HPF (0 = disable, 1 = enable)
P03 select 6.5MHz HPF (0 = disable, 1 = enable)
P04 select 1.5MHz HPF (0 = disable, 1 = enable)
P05 bypass all HPFs (0 = disable, 1 = enable)
P06 6M low noise amplifier (0 = disable, 1 = enable)
P07 disable T/R relay (0 = enable, 1 = disable)
P10 select 30/20m LPF (0 = disable, 1 = enable)
P11 select 60/40m LPF (0 = disable, 1 = enable)
P12 select 80m LPF (0 = disable, 1 = enable)
P13 select 160m LPF (0 = disable, 1 = enable)
P14 select 6m LPF (0 = disable, 1 = enable)
P15 select 12/10m LPF (0 = disable, 1 = enable)
P16 select 17/15m LPF (0 = disable, 1 = enable)

Wie immer findet Ihr die neue Version im Forum zum Download.

Neu im Forum, Modifizierte Versionen von openHPSDR und HPSDR/PowerSDR für den Red Pitaya von Detlev DL4AOI Stand 3.3.9

Alle Modifikationen haben in Zukunft CQNRW im Päfix zur besseren Unterscheidung zum Original.
Eine ausfürliche Beschreibung von Detlef zu den Modifikationen wird noch in einem seperaten Beitrag erscheinen.

CQNRW_PowerSDR339_mod.zip : Wie gehabt die modifizierte PowerSDR Software 3.3.9.
CQNRW_sdr_transceiver_hpsdr_0.94-1191_mod.zip : Wie gehabt der modifizierte und compilierte Code von Pavel für den RedPitaya.

CQNRW_Modified_Sources_of_PowerSDR_HPSDR_mRX_PS_v339.zip : Der Source Code der modifizierten Module.
CQNRW_Modified_Source_of_sdr_transceiver_hpsdr_0.94-1191_201608.zip : Der Source Code der modifizierten Module.

CQNRW_RedPitaya_SDRTransceiverHPSDR_QuickStartImage_lt_2GB.zip :
Das Image basiert auf einer RP-Version von Dez. 2015, die ich seit Februar hier verwende. Dazu Pavels 0.94-1191 plus Modifikation und die rc.local (Autostart).
Also das Image auf die SD-Karte und fertig. Man muß nur noch die IP Adresse des RedPitaya herausfinden und in PowerSDR eintragen.
Dabei ist es mir aber gelungen, die Größe auf ca. 1,7GB zu schrumpfen, so daß es auch auf eine SD mit 2GB passen sollte.

Nachtrag :

Das Programm CQNRW_PowerSDR339_mod.zip kann nicht nur für den Red Pitay verwendet werden, diese Version kann auch bei allen anderen Hardware-Konfigurationen wie Hermes etc. eingesetzt werden.

Was ist der Vorteil dieser Modifikation von Detlev (DL4AOI), ich kann diese ZIP-Datei überall hin kopieren, entpacken und die Datei PowerSDR.exe aus dem bin Verzeichnis aufrufen.

Das bedeutet, ich kann das Programm so oft ich will aus verschiedenen Verzeichnissen starten, jedes Programm hat seine eigene Database und Skin-Verzeichnis.

Man kann die beiden Verzeichnisse (PowerSDR, PowerSDR mRX PS) aus der originalen Version im Verzeichnis C:\Benutzer\XXXX\AppData\Roaming\FlexRadio Systems in das neue Verzeichnis PowerSDR kopieren. Damit habe ich die Skin´s und die Database aus der Original 3.3.9 übertragen.

Ersetze XXXX durch den Username des PC.

73 Detlev DL4AOI / Jörg DD8JM

Yaesu präsentiert den FT-991A

Yaesu FT-991A

Features
  • Coverage: 160-6m, 2m and 70cm
  • Modes:  SSB/CW/FM/AM/RTTY/PSK/C4FM
  • 32 Bit High Speed Floating Point IF DSP
  • 160-6 meter Built-in Autotuner
  • IF Width & IF Shift
  • Contour & IF Notch
  • CW APF
  • CW Message Memory & Beacon Mode

Hier auch noch ein Nachtrag von der Messe, beeindruckend was allein heute in Mikrophonen an Funktionen steckt.





NEWs HAMLAB detailed specifications

HAMLAB detailed specifications

HAMLAB system architecture:

HAMLAB system arch.png

SDR specifications

Highlights:

Architecture: direct sampling / internal high performance 14-bit A/D and D/A 125Msps converters (no sound card required)
Band coverage: All band receiver with 5 bands transmitter (80,40,20,12/10m)
Transmit power: up to 10W
Wideband Frequency Coverage: 25 kHz – 62.25 MHz
Connection to PC: 1Gbit ethernet or WIFI connection
Software: Power SDR, HDSPR, Gqrx, GNU Radio, GNU Radio Companion and Pothos
Phones and MIC connection: available on the front panel
Secondary Rx and Tx channel: available through BNC connectors

Receiver Specifications:

Architecture: Direct Digital Sampling
ADC Sampling Rate: 125Msps
ADC Resolution: 14 bits
Wideband Frequency Coverage: 25 kHz – 62.25 MHz
MDS (min. detectable signal): MDS (typ)@ 500Hz BW
Preamp OFF@14MHz is -113dBm
Preamp +15dB@14MHz is -130dBm
Preamp +30dB@50MHz is NA
More MDS measurements.

Transmitter Specifications:

Architecture: Direct Digital Up-conversion
TX DAC Sampling Rate: 125Msps
TX DAC Resolution: 14 bits
RF Output Power: up to 10W CW and SSB at @ 13.8V input voltage (max. 15V)
Transmitter Frequency Range: 80 – 10m (amateur bands only)
Low Pass PA Filter Bands: 80, 40, 20, 12/10 m (possibility to changed it to any range 1.8 – 50MHz)
Emission Modes Types: not limited by HAMLAB hw, depending on 3rd party SDR software used
Harmonic Radiation: better than -45 dB
3rd-Order IMD: better than -35 dB below PEP @ 14.2 MHz 10 Watts PEP
Microphone connector: RJ45
Microphone impedance: 600 ohm unbalanced

General Specifications:

Frequency Stability: TBD
Antenna Connector: SO-239 UHF connector
Antenna Impedance: 50 Ohm Unbalanced
RF Output Power: up to 10W CW and SSB at @ 13.8V input voltage (max. 15V)
Maximum Interconnect Cable Length Ethernet: 100 meters (328 feet), Category 5 cable
Power connector: PowerPole

Measurement instruments specifications

Oscilloscope

Input channels 2
Input channels connector BNC
Bandwidth 50 MHz
Resolution 14 bit
Memory depth 16384 Samples Max.
Sampling Rate 125 MS/s
Input range +/- 1V or +/- 20V
Input coupling AC/DC
Minimal Voltage Sensitivity ± 0.244 mV / ± 2.44 mV
External Trigger connector BNC
Input coupling AC/DC

Signal generator

Output channels 2
Output channels connector BNC
Bandwidth 50 MHz
Resolution 14 bit
Signal buffer 16384 Samples Max.
Sampling Rate 125 MS/s
Output range +/- 1V
Frequency Range 0 – 50 MHz
Output impedance 50 ohm
External Trigger connector BNC

Spectrum analyzer

Input channels 2
Input channels connector BNC
Bandwidth 0 – 62 MHz
Dynamic Range – 80dBm
Input noise level < -119 dBm/Hz
Input range +/- 1V
Frequency Range 0 – 50 MHz
Input impedance 1 MΩ / 10 pF
Spurious frequency components -90 dBFS Typically

Logic analyzer

Input channels 8
Max. sample rate 125 MS/s
Fastest input signal 50 MHz
Supported protocols: I2C, SPI, UART
Input voltage levels 2.5V – 5.5V
Threshold: 0.8V for logic low
2.0V for logic high
Input impedance 100kohm 3pF
Sample depth 1MS (typical*)
Trigger resolution 8 ns
Min. detectable pulse length 10 ns
  • Acquired data is compressed therefore the size of data than can be captured depends on activity of signal on LA inputs.
    For I2C, SPI & UART signals 1MS is typical sample depth.

All instrumentation applications are WEB based and don’t require the installation of any native software.
Users can access them via a browser using their smartphone, tablet or a PC running any popular operating systems (MAC, Linux, Windows, Android and iOS).

General Electrical specifications:

Power Requirements: +13.8V DC nominal ±15% (Transmitter output specified at 13.8VDC)
Power Consumption: TBD

Mechanical specifications:

Height: TBD
Width: TBD
Depth: TBD
Weight: TBD
Operating temperature: TBD
